Main

Main Frame Fabricated by Welding of St-52 or equivalent Cross Member as per IS : 2062

Axie

10 Stud. axie capacity 12000kgs at 105 km/hr Speed (2 Nos.)

Suspension

Over Slung, tandem multi-leaf spring suspension

King Pin

Standard Welding tpe Size 50.2 mm

Landing Gear

Standard 80 ton load capacity/ pair

Brake System

Full air Brake, double line compressed air system. The Compressed air to be taken from truck tractor through air hoses & connectors

Rims

7.5 * 20 10 Std 8 Nos

Tyres

10.00-20 8 Nos

Electric System

7 way socket, Tail Lamp with Guards

Painting

1 coat of anti- corrosive primer & 2 coat of finish paint

Rubbing Plate

Thickness 12 mm

Aeration Cloth

Polyester solid woven PTFE Treated in tubular form

Valves

Rubber coated butterfly type Audco make

Material Pipe Line

'C' Class 125mm N.B. Tata make

Air Pipe Line

'B' Class 75 & 50mm N.B. Tata make

Mudguards

Made out of 2mm Thick M.S. Sheet Supported properly

Main Hole

2/3 Nos with 6 Nos Locking bolts
